CaseIH 3594 vs Deere 6140R (2013–2014)
Specification differential, power-to-weight analysis, hydraulic benchmarks, and equipment decision guidance.
CaseIH 3594
Category: Farm
Deere 6140R (2013–2014)
Category: Farm
Decisive Performance Differentials
- CaseIH 3594 provides +47.9 PTO HP more implement shaft power
- CaseIH 3594 provides +3,005 lbs more unballasted traction mass
Multi-Axis Capability Radar
Normalized 5-pillar operational benchmark comparison
Dual Field Action & Powertrain Sound
Side-by-side operational field footage verified with computer vision & acoustic audits.
Head-to-Head Specification Differential
Side-by-side technical parameters with calculated delta advantage & percent differentials
| Specification | CaseIH 3594 | Deere 6140R (2013–2014) | Advantage Delta |
|---|---|---|---|
| Power & Output | |||
Rated Engine Horsepower | 202 HP | 154 HP | - |
PTO Horsepower (Tested) | 182.3 HP | 134.4 HP | +35.6%+47.9 PTO HP (+35.6%) |
Traction Density Ratio | 11.5 HP/1k lbs | 10.6 HP/1k lbs | 11.5 vs 10.6 HP / 1,000 lb (higher transport agility) |
| Dimensions & Weight | |||
Base Operating Weight | 17,590 lbs | 14,585 lbs | +20.6%+3,005 lbs heavier |
| Engine Specs | |||
Displacement | 8.3 L | 6.8 L | +1.5L larger displacement |
Cylinders | 6 Cylinders | 6 Cylinders | - |
| Hydraulics & Implements | |||
Standard Hydraulic Pump Flow | N/A (Check Option Pack) | 26.4 gpm | - |
Rear SCV Remotes (Standard) | 2 Valves | 3 Valves | +1 extra standard remote circuits |
3-Point Hitch Category | Category III | Category III/IIIN | - |
| Chassis & Drivetrain | |||
Drive Configuration | 2WD (Optional 4WD) | 4WD | - |
Transmission System | partial power shift | four-speed power shift | - |
Buyer Decision Export Tools
Export side-by-side data for forums, Excel spreadsheets, or dealer negotiations
Operational Field Verdict Matrix
Algorithmic suitability assessment cross-referencing Nebraska draft tests against four agricultural workloads.
Primary Tillage & Deep Chisel Plowing
CaseIH delivers higher base frame ballast (+3,005 lbs) to minimize tire wheel slip under deep draft implement drag.
Large-Scale Air Seeding & Hydraulic Drills
Dedicated remote circuit hydraulic flow ratings are incomplete. Direct comparative seeding capacity requires dealer-verified option build sheets.
Road Hauling & Grain Cart Chase Duty
CaseIH 3594 has a sharper 11.48 HP/1,000 lb power-to-weight ratio for rapid hill-climbing acceleration with loaded grain carts.
Soil Compaction & Wet Ground Flotation
Deere 6140R (2013–2014) features a lighter footprint (-3,005 lbs), mitigating subsoil compaction and preserving soil porosity.
Select CaseIH 3594 for superior tractive frame ballast and engine power reserves across evaluated field tasks.
Decision Analysis & Editorial Verdict
CaseIH 3594 holds the specification advantage across verified metrics, led by higher rated horsepower. For heavy field draft tasks, evaluate 3594; for operations sensitive to operating costs or implement compatibility, Deere 6140R (2013–2014) remains a direct benchmark contender.
